Station M3 Geek PC,Open Source 8K Android TV Box, RK3588S, Up to 16GB RAM, Well-designed system Station OS for Entertainment and Geek

Name: Station M3 Geek PC,Open Source 8K Android TV Box, RK3588S, Up to 16GB RAM, Well-designed system Station OS for Entertainment and Geek
Brand: youyeetoo geeker shop
Price: 248 USD
Availability: InStock
Rating: 5 (4 reviews)

Station M3 Entertainment · Geek PC, Arm Mini PC
All-new upgrade. Beyond Imagination.
Key Feature:
-CPU : RK3588s Octa-core CPU, Support Real 8K Video
-Wireless: Onboard 2.4GHz / 5GHz dual-band WiFi, 802.11 a/b/g/n/ac protocol, Bluetooth4.2
-Open Source Mainborad: The motherboard used provides a complete development SDK for Android, linux and other systems.
Applicatoin:
-Mini Personal Computer/ Big-Screen Android 12 Phone / Family NAS / Classic Game PC

5 (4 Reviews)

$248.00

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (0)

Description
Reviews

For downloading the Tools, Driver and Firmware use the following link:
https://youyeetoo.com/blog/station-m3-tqdp3588s0001-190

Tips:The motherboard ROC-RK3588S-PC used provides a complete development SDK for Android, linux and other systems.

Motherboard Performance Test Video

New-gen Processor RK3588S

The breakthrough new-gen processor RK3588S is now in Station M3. CPU of M3 delivers 4x performance and GPU 8x than the previous generation. Powerful M3 is ready to work, watch, or play as long as you need it.

Real 8K Video

8K video encoding and decoding. 8K video output.

Dual Screens Display 8K Video

With only one Type-C cable, you can connect the screen and M3 to display 8K HD video. Plug and play. HDMI display output is supported, which means it can support two screens to display 8K video at the same time. Multi-purpose M3 for more possibilities.

Product parameters

Basic Specifications
CPU	RK3588S Octa-core 64-bit CPU, clock speed up to 2.4GHz, Mali-G610 MP4 GPU NPU computing power up to 6 TOPS
Video Decoding	8K@60fps H.265/VP9/AVS2, 8K@30fps H.264 AVC/MVC 4K@60fps AV1 1080P@60fps MPEG-2/-1/VC-1/VP8
RAM	4GB/8GB/16GB LPDDR4
Storage	32GB/64GB/128GB/256GB eMMC
Storage Expansion	M.2 SATA3.0 (2242) ×1 Support SATA3.0 SSD (default) Compatible with PCIe2.0 NVMe SSD TF card slot ×1
Hardware Specifications
Wireless	2.4GHz / 5GHz dual-band WiFi, 802.11 a/b/g/n/ac protocol, Bluetooth4.2
Ethernet	1000Mbps Ethernet (RJ45 ) ×1
Video Output	HDMI2.1 (8K@60fps or 4K@120fps) ×1 DP1.4 (USB-C multi-function port, 8K@30fps) ×1
Audio Output	3.5mm audio jack ×1
USB	USB3.0 (current limit: 1A) ×1 USB2.0 (current limit: 500mA) ×1 USB-C multi-function port (USB3.0 OTG/DP1.4, current limit: 2A) ×1
Power	DC12V input (5.5×2.1mm, recommend 12V/1.5A or above)
OS/Software
OS	Station OS (default) Support Android, Ubuntu and more
General
Dimension	96.6mm×73mm×32.8mm
Button	Power button ×1 Recovery button (at the bottom of the 3.5mm audio jack) ×1
Power Consumption	Idle: ≈0.42W (12V/35mA) Typical: ≈3W (12V/250mA) Max: ≈14.4W (12V/1200mA)
Environment	Operating Temperature: -20℃～60℃ Storage Temperature: -20℃～70℃ Storage Humidity: -40%～70 %
