BPI-M64 Single Board Computer Allwinner A64 chip design,2 GB DDR3 RAM and 8G eMMC

SKU: BP0024
BPI-M64 is a 64-bit quad-core mini single board computer. It features 2GB of RAM and 8GB eMMC. It also has onboard WiFi and BT. On the ports side, the BPI-M64 has 2 USB A 2.0 ports, 1 USB OTG port, 1 HDMI port, 1 audio jack, and lastly a DC power port. The processor is pin-to-pin comptialbe with R18, so it comes with two versions:M64 and M64-R18.BPI-M64 is an open platform device, it is for anyone who wants to play and build with developer technology instead of simply using consumer technology.
0.0 (0 Reviews)
$65.79 $40.76
Received successfully
Coupon Code
CONTINUE SHOPPING
    Please select the information you wantX
Quantity
-
+
  • BPI-M64 with Allwinner A64 chip design,2 GB DDR3 RAM and 8G eMMC
  • BPI-M64 with Allwinner A64 chip design,2 GB DDR3 RAM and 8G eMMC
  • BPI-M64 with Allwinner A64 chip design,2 GB DDR3 RAM and 8G eMMC
  • BPI-M64 with Allwinner A64 chip design,2 GB DDR3 RAM and 8G eMMC
  • BPI-M64 with Allwinner A64 chip design,2 GB DDR3 RAM and 8G eMMC
Frequently Bought Together
more
Frequently Bought Together
  • Description
  • Reviews

Banana pi BPI-M64

Allwinner A64 1.2 Ghz Quad-Core ARM Cortex A53 64-Bit Processor


SHOPPING LIST : 1 * BPI-M64
Hardware inerface:



Hardware spec:

HardWare Specification of Banana pi BPI-M64
CPU Allwinner 64 Bit Quad Core ARM Cortex A53 1.2 GHz CPU
GPU Dual core Mali 400 MP2 GPU
Memory 2GB LPDDR3 (shared with GPU)
Storage MicroSD slot with support for up to 256GB expansion and 8G eMMC flash with support for up to 64GB
Network 10/100/1000 Mbit/s Ethernet + Wi-Fi 802.11 b/g/n + Bluetooth 4.0
Video Input(s) A CSI input connector allows for the connection of a designed camera module
Video Output(s) 1080p capable HDMI port and multi-channel audio output (NO H./X.265 capabilities)
Audio Input(s) On board microphone
Audio Output(s) 3.5mm jack and HDMI
USB ports USB 2.0 PORT (x2), USB OTG (x1)
Remote IR Receiver
GPIO 40 Pin Header : GPIO (x28) and Power (+5V, +3.3V and GND). GPIO pins can be used for UART, I2C, SPI or PWM
Switches Reset, Power and U-boot
LED Power Status and 8P8C
Power Source 5 volt @2A via DC Power and/or Micro USB (OTG)
Size & Weight 92x60mm, 48g
OS Android and Linux
