Overview
PoE splitter,it is an economical and practical PoE remote power equipment base on IEEE802.3af/at/bt standard. It can separate the power and data via cable transmission. Proper matching use with POE switch or PSE injector which meets standard IEEE802.3af/at/bt, Provides power and data at the same time for the terminal device does not support PoE. PoE splitter, the output voltage of 12V used with the power supply equipment, It helps to expand wireless city, Security monitoring, and other POE practical places and is not restricted by the layout of the power line.
Features
Technical Parameters
|
Model |
PS1260BT |
|
Transfer Rate |
10/100/1000M |
|
Power |
Input 42.5-57V/600mA , Output 12V/5A MAX |
|
Standard |
IEEE802.3 af/at/bt(60W) |
|
TRNF |
1/2(+),3/6(-);4/5(+),7/8(-) |
|
Interface Type |
1 Input RJ45 port, 1 output RJ45 port, 1 DC output |
|
Standard |
IEEE 802.3 I, IEEE 802.3 u, IEEE 802.3 x, IEEE802.3 af， IEEE802.3at， IEEE802.3bt |
|
LED |
Yellow PoE lamp |
|
Environment |
Work within -20~50°,Storage within -30~60° Work within 10%~90% Non-condensing,Storage within 5%~95% Non-condensing |
|
Dimension |
81*61*26mm |
|
Weight |
0.5kg |
