Rock960c - Rock960 Board - Based on the RK3399 SoC

SKU: WM0004
The Rock960c is based on the RK3399 SoC which is a Dual Cortex-A72 + quad Cortex-A53 CPU, with up to 2.0GHz frequency. This board comes packed with 1GB, 2GB or 4GB of RAM, on board eMMC socket, USB 3.0 type C with DP, HDMI 2.0 with 4K output, 4 lane M.2 PCI-E 2.1, and so much more! All of this on the 96Boards Consumer Edition Standard form factor, a truly little beast.
0.0 (0 Reviews)
$49.92 $19.97
Received successfully
Coupon Code
CONTINUE SHOPPING
    Please select the information you want X
  • Model C:
    1GB
    2GB
    4GB
    Please select the information you wantX
Quantity
-
+
  • Rock960c - Rock960 Board - Based on the RK3399 SoC
  • Rock960c - Rock960 Board - Based on the RK3399 SoC
  • Rock960c - Rock960 Board - Based on the RK3399 SoC
  • Rock960c - Rock960 Board - Based on the RK3399 SoC
Frequently Bought Together
more
Frequently Bought Together
  • Description
  • Reviews

ROCK960 model C

96Boards Compliant Board


Detail:
https://www.96boards.org/product/rock960c/

Quick Start :
https://www.96boards.org/documentation/consumer/rock/rock960c/getting-started/

Additional Information

Component Description
SoC Rockchip RK3399
CPU ARM Cortex-A72 Dual-core up to 1.8GHz + Cortex A53 Quad-core up to 1.4GHz
GPU ARM Mali T860MP4
RAM 1GB or 2GB or 4GB LPDDR4, 3200Mb/s
PMU RK808-D
Storage Reserve eMMC socket on board, optional eMMC module up to 128GB, uSD card up to 128GB
Ethernet Port USB 2.0/3.0 expansion
Wireless WLAN 802.11 ac/a/b/g/n, 2.4GHz and 5Ghz, Bluetooth ® wireless technology 4.2. On board WLAN/BT antennas, optional IPEX antenna.
USB 1 x USB 3.0 host type A, 1 x USB 3.0 OTG type A and 1 x USB 2.0 type C(host only)
Display 1 x HDMI 2.0(Type A - full) up to 4Kx2K@60Hz, 1 x 4L - MIPI DSI up to 1080p@60Hz
Video Inside decoder: H.264 10bit up to HP level 5.1 - 2160p@60fps (4096x2304), VP9 - 2160p@60fps(4096x2304), H.265/HEVC 10bit - 2160p@60fps(4096x2304), MPEG-1, MPEG-2, MPEG-4, H.263, VP8, VC-1.
Audio HDMI output
Camera 1 x 4-lane MIPI CSI, 1 x 2-lane MIPI CSI
Expansion Interface 40 pin low speed expansion connector: +1.8V, +5V, DC power, GND, 2UART, 2I2C, SPI, I2S, 12xGPIO and 60 pin high speed expansion connector: 4L-MIPI DSI, I2C x2, SPI (48M), USB 2.0, 2L+4LMIPI CSI
LED 1 x WiFi activity LED(Yellow), 1 x BT activity LED (Blue) and 4 x User LEDs (Green)
Button Reset button, Maskrom button, Loader button
Power Source Recommend a 12V@2A adapter with a DC plug which has a 4.75mm outer diameter and 1.7mm center pin with standard center-positive (EIAJ-3 Compliant)
OS Support AOSP/Debian/Ubuntu/Fedora/LibreELEC/Lakka/FlintOS
Size 85mm x 55mm
